Flow Meter LC M10

Deskripsi

Flow Meter LC M10

Max Flow Rate : 550 LPM

Size 2 Inchi

Flow Meter LC Type M10

Spesification :

Accuracy/Performance :

Repeatability : Capable of 0.02% or better at any flow rate over entire range

Linearity.

Over 5:1 range

Mech. registration: capable of ± 0.125% or better from max. nom. flow rate

Elect. registration: capable of ±0.10% or better from max. nom. flow rate

Over 10:1 range

Mech. registration: capable of ±0.22% or better from max. nom. flow rate

Elect. registration: capable of ± 0.10% or better from max. nom. flow rate

Over 40:1 range

Mech. registration: capable of ±0.5% or better from max. nom. flow rate

Elect. registration: capable of ±0.15% or better from max. nom. flow rate

Temperature range : -40° F to 160° F (-40° C to 71° C)

Capacity : 550L/Min ( 150GPM )

Max Pressure : 10.5bar / 150PSI

Type : Direct Reading

Conection : Anzi Flanged , NPT , BSPT , Slip Walled Available

Construction :Meter housing and rotors Cast aluminum or stainless steel

Internal components : Aluminum, Ni-Resist, stainless steel

Seal materials : UL recognized component Buna-N, Viton®1 , Teflon®1

Bearings : Carbon, Teflon, Ni-Resist

Industries served

LC M and MA series meters are well suited for use in industries requiring precise flow measurement and reliable, extended servicelife:

• Refined petroleum products ,Aviation fuels, LPG ,Agricultural chemicals, Paints and coatings, Foods and beverages, Petrochemicals, Pharmaceuticals, Cosmetics, Printing Inks ,Textiles .

Construction

Meter housing and rotors

Cast aluminum

Internal components

Aluminum, Ni-Resist, stainless steel

Seal materials

UL recognized component : Buna-N, Viton®1, Teflon®1

Bearings

Carbon, Teflon, Ni-Resist 1Viton and Teflon are registered trademarks ofDuPont Corporation.
